| Parameter | 1200CG24XX | 1200CG48XX | 1200CG60XX | 1200CG72XX | 1200CG84XX |
|---|---|---|---|---|---|
| Rated output power | 1200 W | ||||
| Rated output voltage | 24 V | 48 V | 60 V | 72 V | 84 V |
| Max output voltage | 34 V | 60 V | 73 V | 88 V | 103 V |
| Max output current | 25 A | 25 A | 25 A | 20 A | 15 A |
| AC input voltage range | 110–250 V AC · 50/60 Hz | ||||
| AC input max current | 12 A @ 120 V AC | ||||
| Power factor | ≥ 0.99 | ||||
| Efficiency | ≥ 90 % | ||||
| Noise | ≤ 45 dB | ||||
| IP rating | IP65 | ||||
| Net weight | 2.2 kg | ||||
| Operating temperature | −30 °C … +65 °C | ||||
| Storage temperature | −40 °C … +95 °C | ||||
| Application | Golf cart, utility vehicle and low-speed EV battery packs — lead-acid and lithium | ||||
| Compliance | UL / CB / CE / PSE / RCM / FCC / CEC / DOE / CP65 directives | ||||
Values per the WT series 1200 W (1.2 kW) on-board charger specification sheet.
| Item | Detail |
|---|---|
| Brand / Origin | XCONTACTOR · China |
| MOQ & Lead Time | 1 pc for sample · typically 2–4 weeks (confirm with sales) |
| Payment & Warranty | T/T, PayPal, Trade Assurance · 1 year warranty |
