| Parameter | 144 V platform | 312 V platform |
|---|
| AC Input |
| Input voltage range | AC 90–265 V |
| Frequency | 47–63 Hz |
| Input current | ≤ 32 A |
| Power factor | ≥ 0.98 @ ≥ 3300 W |
| Starting inrush current | ≤ 48 A |
| DC Output — On-Board Charger |
| Output voltage range | 95–202 V | 200–450 V |
| Max output current | 46 A | 20 A |
| Output power | 6600 W @ 220 V AC · 3300 W @ 110 V AC |
| Output way | CV / CC |
| Efficiency | ≥ 93 % |
| CV accuracy | ± 1 % |
| CC accuracy | ± 2 % |
| Ripple voltage coefficient | ± 5 % |
| Output voltage rising time | < 5 s, overshoot < 10 % |
| Shut-off response time | Current below 10 % in 300 ms, down to 0 A in 500 ms |
| Stand-by power consumption | ≤ 5 W |
| Low Voltage Output — DC/DC |
| Output way | CV |
| Output voltage | 12 V |
| Nominal current | 5.5 A |
| CV accuracy | ± 2 % |
| Output power | ≥ 66 W |
| Ripple voltage coefficient | ≤ 1 % |
| Low Voltage Interface |
| CAN communication | Yes |
| Baud rate | 125 kbps / 250 kbps / 500 kbps, optional |
| Terminal resistance | Not available |
| Application | Electric vehicle, marine and golf cart battery packs — 144 V and 312 V platforms |
