| Parameter | 3000BG24XX | 3000BG36XX | 3000BG48XX | 3000BG60XX | 3000BG72XX | 3000BG96XX |
|---|---|---|---|---|---|---|
| Rated output power | 3000 W | |||||
| Rated output voltage | 24 V | 36 V | 48 V | 60 V | 72 V | 96 V |
| Max output voltage | 33 V | 50 V | 68 V | 84 V | 103 V | 120 V |
| Max output current | 50 A | 50 A | 50 A | 35 A | 35 A | 30 A |
| AC input voltage range | 120 V AC / 200–240 V AC · 50/60 Hz | |||||
| AC input max current | 13 A @ 120 V AC · 15 A @ 220 V AC | |||||
| Power factor | ≥ 0.99 | |||||
| Efficiency | ≥ 90 % | |||||
| Noise | ≤ 55 dB | |||||
| IP rating | IP65 | |||||
| Net weight | 6 kg (13.2 lb) | |||||
| Operating temperature | −30 °C … +65 °C | |||||
| Storage temperature | −40 °C … +95 °C | |||||
| Application | Golf cart, utility vehicle and low-speed EV battery packs — lead-acid and lithium | |||||
| Compliance | UL / CB / CE / PSE / RCM / FCC / CEC / DOE / CP65 directives | |||||
Values per the WT series 3000 W (3 kW) on-board charger specification sheet.
| Item | Detail |
|---|---|
| Brand / Origin | XCONTACTOR · China |
| MOQ & Lead Time | 1 pc for sample · typically 2–4 weeks (confirm with sales) |
| Payment & Warranty | T/T, PayPal, Trade Assurance · 1 year warranty |
