HFE85P-350 HONGFA High voltage DC Contactor 1000V 150A 4v dc 12V DC

stars, based on 0reviews

$48.00 unit

Battery Type

Product Detai Referenc

Modle Paramenter name		HFE85P-350




Rated current		350A
Rated current		350A
Rated voltage		DC12～1000V
Rated voltage		DC12～1000V
Insulation voltage		1000MΩ DC1000V
Insulation voltage		1000MΩ DC1000V
Number of poles		Single pole
Number of poles		Single pole
Type of circuit		DC
Type of circuit		DC
Mechanical life		200,000times
Mechanical life		200,000times
Electrical endurance	Breaking	50ops(450VDC,-300A) 1000ops(450VDC,300A)
		50ops(450VDC,-300A) 1000ops(450VDC,300A)
		100ops(1000V,300A)
		100ops(1000V,300A)
Max. breaking current		2000A(320VDC)1op
Max. breaking current		2000A(320VDC)1op
Operate time (at rated volt.)		≤30ms
Operate time (at rated volt.)		≤30ms
Release time (at rated volt.)		≤10ms
Release time (at rated volt.)		≤10ms
Insulation resistance		≥1000MΩ(1000 VDC）
Insulation resistance		≥1000MΩ(1000 VDC）
Withstand voltage	Between coil & contacts	3300 VAC 1min


	Between open contacts	3300 VAC 1min


	Between contacts & auxiliary contacts	3300 VAC 1min


Rated control voltage Uc		Rated control voltage：DC12V/24V Pick-up voltage：≤75% Un
Rated control voltage Uc		Rated control voltage：DC12V/24V Pick-up voltage：≤75% Un
Max. switching power		450kW
Max. switching power		450kW
Max. switching voltage		1000VDC
Max. switching voltage		1000VDC
Workplace Temperature		（-40ºC ~ 85ºC）
Workplace Temperature		（-40ºC ~ 85ºC）
Shock resistance	Functional	196m/s2



	Destructive	490m/s2

Product Dimension Drawing

Endurance Capacity Curve

吸合电压/释放电压曲线图/Pick-up Voltage/Drop-out Voltage Curve
