Beiamp
3kW/3000W on board charger/ 72V35A/60V35A/48V50A/24V50A/Factory supply
stars, based on 0reviews
Quantity
Price
10+
$367.08
100+
$327.18
Product Tag:
3kw chargerlithium battery chargerOBC charger3kW/3000W on board charger/ 72V35A/60V35A/48V50A/24V50A/Factory supplyon board chargeron-board chargeron-board charger electric vehiclecharger for electric carFactory supplyElectric Car ChargerShort-circuit protection3KW Off-Board Electric Vehicle Charger1.8KW ChargerEV charger3.3 kw on-board charger for electric vehicle6.6kW chargerProduct Detai Reference
|
|
3000BG24XX |
3000BG36XX |
3000BG48XX |
3000BG60XX |
3000BG72XX |
3000BG96XX |
|
|
|
Rated voltage |
24V |
33V |
48V |
60V |
72V |
96V |
||
|
Max output voltage |
33V |
50V |
68V |
84V |
103V |
120V |
||
|
Max output current |
50A |
50A |
50A |
35A |
35A |
30A |
||
|
Rated voltage AC |
120VAC/200~240VAC;50/60Hz |
|||||||
|
AC Input Max current |
||||||||
|
PF |
≥0.99 |
|||||||
|
EffIciency |
≥90% |
|||||||
|
Noise |
≤55dB |
|||||||
|
IP Rating |
IP65 |
|||||||
|
Net Weight |
6kg(13.2lb) |
|||||||
|
Operating Temperature |
(-30~65℃) |
|||||||
|
Storage Temperature |
(-40℃~95℃) |
|||||||
|
Comoliance |
UL/CB/CE/PSE/RCM/FCC/CEC/DOE/CP65 directives |
|||||||
- Warranty:
- 2 Years
- Application:
- CAN BUS
- Application2:
- Auxiliary Power
- Application3:
- Application4:
- External Indicator
- Application5:
- Infrared
- Product Name:
- 3kW/3000W on board charger/ 72V35A/60V35A/48V50A/24V50A/Factory supply
- Brand Name:
- Beiamp
- Model Number:
- WT series
- Place of Origin:
- Jiangsu, China
- Certification:
- UL/CB/CE/PSE/RCM/FCC/CEC/DOE
- AC Input:
- 110~240VAC
- Hertz:
- 50Hz/60Hz
- AC Input Max Current:
- 13A@120VAC 15A@240VAC
- Power Factor:
- ≥0.99
- Efficiency:
- ≥90%
- Noise:
- ≤45dB
- DC Output Voltage:
- 57.6V
- DC Output Current:
- 50A
- Battery Type:
- Lifepo4/NMC
